TP-Link 2.4GHz 300Mbps 12dBi Outdoor CPE – TL-CPE220

Long-Range Outdoor Connectivity

The TP-Link 2.4GHz 300Mbps 12dBi Outdoor CPE – TL-CPE220 delivers stable wireless performance across long distances. Its built-in 12dBi directional antenna provides stronger signal focus, ensuring reliable connections with minimal interference. In addition, it operates on the 2.4GHz band at speeds up to 300 Mbps, making it suitable for outdoor video surveillance, internet sharing, or point-to-point links.

Built for Harsh Environments

The TL-CPE220 is enclosed in a durable weatherproof housing that protects it against rain, sun, wind, and dust. This makes it ideal for outdoor deployment in both urban and rural settings. Moreover, with professional-grade lightning protection and anti-UV casing, the device ensures stable performance even in extreme conditions.

Easy Deployment and Flexible Management

With Passive PoE support, the TP-Link TL-CPE220 can be installed up to 60 meters away from the power source, offering flexible positioning. Setup and management are simplified through the Pharos Control software, which allows centralized configuration of multiple devices. Furthermore, it supports multiple modes such as Access Point, Client, Repeater, and Bridge, giving you adaptability for different networking scenarios.

Technical Specifications

Wireless

• Wi-Fi Standard: IEEE 802.11b/g/n

• Frequency: 2.4 – 2.4835 GHz

• Wireless Speed: Up to 300 Mbps (2.4GHz)

• Antenna: Built-in 12 dBi directional

• Transmission Power: Up to 30 dBm / 1000 mW (adjustable)

Hardware

• Ports: 1 × 10/100 Mbps Ethernet Port (Passive PoE in)

• Buttons: Reset

• Power Supply: Passive PoE (24 V, up to 60 m)

Features

• Operation Modes: AP, Client, Repeater, Bridge, AP Router

• Centralized Management: Pharos Control software

• MAX Range: Up to 12 km+ (depending on environment)

• Security: WPA/WPA2, WPA-PSK/WPA2-PSK encryption

Protection & Durability

• Weatherproof enclosure (IPX5)

• 6000V lightning protection

• UV resistant casing

Dimensions & Power

• Dimensions: 8.8 × 3.1 × 2.4 in (224 × 79 × 60 mm)

• Power Consumption: 10.5 W Max
